| Item | Function | LBM 10 |
|---|---|---|
| Travel | X axis | 250mm |
| Y axis | 250mm | |
| Z axis | 250mm | |
| Table | Table specification | 1 table |
| Standard table dimension | 200×200mm | |
| Option: rotary table dimension | φ150 | |
| Max load | 50kg | |
| Height | 813mm | |
| Feed rate | X,Y,Z axis | 0～20000mm/min |
| (0～max output) rise up time | 0.1s | |
| Electric motor | X,Y,Z axis | 400w |
| Power source | Power supply |
AC200V±10% 50/60Hz±1Hz |
| Air pressure |
Not less 0.4MPa Not less 250NL/min |
|
| Pneumatic | Main device | Mist separator & Regulator Solenoid valve, pressure switch, etc. |
| Lubrication | Ball screw | Grease lubrication |
| Running condition | Temperature | 5～35℃ |
| Humidity | 20～80%RH | |
| Size | Height | 2,250mm |
| Dimension | 1,050×1,110mm | |
| Accessory |
eveling Bolts, Machine light, Laser light shielding cover Sheet air device, Ring blow device |
|
| Supported laser |
① Direct Diode Laser
② Fiber out Diode Laser

③ Fiber Laser and others |
|
